For using PowerShell in Applications Manager, you need the latest Windows Management Framework (Windows PowerShell 5.0) on both Applications Manager server and the remote Windows server.
Powershell - Enable Script Execution
Powershell script execution must be enabled on Applications manager server for data collection. Here is how you can do it:
Configure Powershell Script Execution via Group Policy Editor
- Open the Group Policy Editor from Control Panel → Edit Group Policy (or) run gpedit.msc from Start menu.
- To configure, navigate under Computer Configuration to Policies\Administrative Templates\Windows Components\Windows PowerShell.
- You should see a setting called Turn on Script Execution like in the following image:
- Double-click the setting. You will want to enable it and select an option from the drop down.
- Set it to “Allow All Scripts”.
- Click Apply and OK.
Enable and Use Remote Commands in Windows PowerShell
Ensure that Windows PowerShell is enabled in both servers:
- Open Control Panel.
- Select Programs and Features.
- In the Tasks list, click Turn Windows features on or off.
- When the Server Manager console opens, check if Windows PowerShell is enabled.
Ports required for PowerShell remoting - Default: TCP 5985 and 5986
You can verify the availability of Windows Remote Management (WinRM) service and configure PowerShell for remoting by following these steps:
- Start Windows PowerShell as an administrator by right-clicking the Windows PowerShell shortcut and selecting Run As Administrator.
- To configure Windows PowerShell for remoting, type the following command:
- Configure the TrustedHosts setting on both computers, so that computers will trust each other:
On Remote Monitored Server:
Set-Item wsman:\localhost\client\trustedhosts <Applications Manager hostname>
On Applications Manager Sever:
Set-Item wsman:\localhost\client\trustedhosts *
- Include the below cmdlets to be execute on remote Windows server when enabling powershell remoting (It's not required to be run on the Applications Manager server):
"Set-Item WSMan:\localhost\Shell\MaxShellsPerUser -value 25 -WarningAction SilentlyContinue" ( To increase the maximum number of concurrent shells that a user can remotely open)
"Set-Item WSMan:\localhost\Shell\IdleTimeout -value 60000 -WarningAction SilentlyContinue" (Determines how long the session stays open if the remote computer does not receive any communication from the local computer, including the heartbeat signal. When the interval expires, the session closes.)
- On both computers, restart the Windows Remote Management (WinRM) so the new settings will take effect: Restart-Service WinRM.
You can test the configuration and connection from Applications Manager by following these steps:
- Open PowerShell Console with administrator privileges.
- Run : $testSession= New-PSSession -ComputerName <REMOTE-HOSTNAME> -Credential Get-Credential
- A popup will appear, give the remote server credentials.
- If any error is thrown, do the required configuration/setup to resolve it.
- If step 3 executes without error, remove the testSession by executing : Get-PSSession | Remove-PSSession
The steps above will test whether the WinRM service is running on the remote computer and if Applications Manager can communicate with the remote server.
