Upgrade APM Insight Java Agent

Manual Upgrade

  • Download the latest agent APM Insight Java Agent (apminsight-javaagent.zip) from here.
  • Extract the zip file to a new directory to find agent jars (apminsight-javaagent.jar and apminsight-javaagent-api.jar) and its configuration files.
  • Navigate to the directory where you have deployed the APM Insight Java Agent in your Application Server.
  • Take a backup of your old apminsight-javaagent.jar and apminsight-javaagent-api.jar in the directory. Then replace them with the new one.
  • Restart the target Application server.

1. Customers upgrading to Applications Manager 14440 or above must upgrade their Java agent to version 4.x or above.
2. While upgrading Java Agent from version 2.x to 4.x or above, the following keys in apminsight.conf file needs to be updated:
          a. license.key value from Applications Manager web client APM Insight tab > Help Card > License Key needs to be added.
          b. apm.host value needs to be changed to https://<appmanager_host>:<ssl_port> or http://<appmanager_host>:<http_port> after upgrade.

Example 1:

Example 2:

Visit Configuration Guide page for more details.
